| 最大频率 | 18 GHz |
|---|---|
| 动态范围 | 117 dB |
| 输出功率 | 0 dBm |
| 轨迹噪声 | 0.015 dBrms |
| 内置端口数量 | 2 端口 |
| 本底噪声 | -127 dBm |
| 扫描速度最高可达 201 个点 | 9 ms |
| 应用 |
|
| 元器件 |
|
| 台式 | 是 |
选件和升级
选件
了解详细信息: 查看配置指南
| Accessories | |||
| E5063A-820 | Add mouse | ||
| E5063A-810 | Add keyboard | ||
| E5063A-1CP | Rack mount and front handle kit | ||
| E5063A-1CN | Front handle kit | ||
| E5063A-1CM | Rack mount kit | ||
| Test set | |||
| E5063A-285 | 2-port test set, 100 kHz to 8.5 GHz | ||
| E5063A-245 | 2-port test set, 100 kHz to 4.5 GHz | ||
| E5063A-2H5 | 2-port test set, 100 kHz to 18 GHz | ||
| E5063A-205 | 2-port test set, 100 kHz to 500 MHz | ||
| E5063A-215 | 2-port test set, 100 kHz to 1.5 GHz | ||
| E5063A-235 | 2-port test set, 100 kHz to 3 GHz | ||
| E5063A-265 | 2-port test set, 100 kHz to 6.5 GHz | ||
| E5063A-2D5 | 2-port test set, 100 kHz to 14 GHz | ||
| Storage | |||
| E5063A-019 | Standard Data Storage | ||
| Calibration documentation | |||
| E5063A-A6J | ANSI Z540-1-1994 Calibration | ||
| E5063A-1A7 | Calibration + Uncertainties + Guardbanding (Not Accredited) | ||
| Features | |||
| E5063A-011 | 时域分析/测试向导 | ||
| E5063A-010 | 时域分析 | ||
| Wireless power transfer | |||
| E5063A-006 | 无线功率传输分析 | ||
| E5063A-721 | Add GPIB | ||
| E5063A-722 | Not required GPIB | ||
| E5063A-732 | Not required Handler IO | ||
| E5063A-731 | Add Handler IO | ||
